Viair Compressor Kit

Viair Compressor Kit

$399.95 USD
$399.95 USD
Sale Sold out

Our 150 PSI On Demand Air System is a Plug N Play solution for any enthusiast who enjoys fast tire inflation and performs multiple pneumatic tasks on the go. Features a 2.0 Gallon tank, pre-wired 145 PSI pressure switch, 1/4″ NPT brass drain cock, 1/4″ NPT ASME Coded and certified safety valve and 1/4″ quick connect coupler pre-installed. The Kit has an onboard ON/OFF switch and can be easily installed in the vehicle using the SAE terminal ring attachments and mounting hardware included.



SPECS:

  • 12-Volt
  • Permanent Magnetic Motor
  • Duty Cycle: 33% @ 100 PSI
  • Max. Working Pressure: 150 PSI
  • Max. Amp Draw: 30-Amps
  • Ingress Protection Rating: IP54
  • Max Ambient Temp: +158°F
  • Min Ambient Temp: -40°F
  • Dimensions: 19″L x 5.9″W x 14.5″H
  • Net Weight: 22.10 lbs.
  • Power Cord Length: 8 ft.

FEATURES:

  • 2.0-Gallon Air Tank
  • 2-Pin SAE Connector Attachment with Terminal Rings
  • 40-Amp Inline Fuse Holder
  • Mounting Hardware
